DUAL IGNITION COIL ASSEMBLY SMD-ELECTRONIC MODULE

Rotax 912 ignition, Rotax 912 dual ignition, Rotax 912 dual ignition coils.

No. Part#

Description

 912UL 912A 912F 912ULS 912S 914UL 914F
1-5 966 215 Double ignition coil 4 4 4 4 4
966 217 Double ignition coil 4 4
2 865 710 Ignition cable, 500mm a a a a a a a
3 860 990 Protection hose 8x1, 560 mm b b b b b b b
4 865 710 Ignition cable 500mm c c c c c c c
5 860 990 Protection hose 8x1, 450mm d d d d d d d
6 842 740 Distance nut M6x24 1 1 1
842 742 Distance nut M6x22.5 1m 1m 1m 1 1 1 1
7 953 390 Separating plate 2m 2m 2m 2 2 2 2
8 945 751 Lock washer A6 11 11 11 12 12 11 11
9 840 883 Allen screw M6x30 2 2 2 2 2 2 2
10 953 125 Ignition coil bracket assembly 2 2 2 2 2 2 2
11 860 710 Rubber buffer 25x20xM6 2 2 2 2 2 2 2
12 960 060 Rubber buffer 25x15xM6 1 1 1 1 1 1 1
860 710 Rubber buffer 25x20xM6 1j 1j 1j 1j 1j
13 247 700 Spacer 6.4/10/5 e e e e e e e
14 851 260 Ignition coil bracket 1 1 1 1 1 1 1 1
15 240 771 Hex screw M6x10 2 2 2 2 2 2 2
16 241 930 Allen screw M6x20 2 2 2 2 2 2 2
17 242 211 Hex nut M6 4 4 4 4 4 4 4
18 241 236 Allen screw M6x16 2 2 2 2 2 2 2
19 965 358 SMD electronic module 2f 2f 2f 2f 2f
20 966 721 SMD electronic module 2g 2g
21 827 800 Washer A5.5 1 1 1 1 1 1 1
22 945 750 Lock washer A5 1 1 1 1 1 1 1
23 240 186 Allen screw M5x25 2 2 2 2 2 2 2
24 851 119 Mass cable assembly 1 1 1 1 1 1 1
25 965 788 Mass cable assembly 1 1 1 1 1 1 1
26 965 781 Mass cable assembly 2 2 2 2 2
27 241 186 Hex screw M6x16 1 1 1 2 2 1 1
28 847 792 Spacer 8.4/12/30 1h 1h 1h 1h 1h 1h 1h
29 851 266 Bracket 1h 1h 1h 1h 1h 1h 1h
851 480 Bracket 1i 1i
30 250 311 Washer 8.4 1h 1h 1h 1h 1h 1h 1h
31 945 752 Lock washer A8 1h 1h 1h 1h 1h 1h 1h
32 240 281 Hex screw M8x50 1h 1h 1h 1h 1h 1h 1h
440 191 Allen screw M8x16 1i 1i
33 851 263 Bracket 1 1 1 1 1 1 1
34 860 731 Protection tube 120mm 2 2 2 2 2 2 2
35 860 741 Marking sleeve 1 2 2 2 2 2 2 2
36 960 742 Marking sleeve 2 2 2 2 2 2 2 2
37 960 743 Marking sleeve 3 2 2 2 2 2 2 2
38 860 744 Marking sleeve 4 2 2 2 2 2 2 2
39 265 240 Suppressed spark plug connector 8 8 8 8 8 8 8
40 866 710 Clamp 20mm 10 10 10 10 10 10 10
41 DCPR7E Spark plug, 20NM COLD! 12mm 8 8 8
DCPR8E Spark plug, 20NM COLD! 12mm 8 8
X27EPRU9 Spark plug, 20NM COLD! 12mm 8 8
42 251 920 Clamp 279x3.5mm 2 2 2 2 2 2 2
43 260 130 Cable grommet NB NB NB NB NB NB NB
44 256 260 Connector housing 4-pole NB NB NB NB NB NB NB
45 265 275 Faston connector NB NB NB NB NB NB NB
46 265 210 Flat pin terminal NB NB NB NB NB NB NB
47 265 262 Connector housing 4-pole NB NB NB NB NB NB NB
48 964 072 Insulation sheath  NB NB NB NB NB
49 964 067 Faston connector 3.96 NB NB NB NB NB
50 964 077 Insulation sheath NB NB NB NB NB
51 964 062 Faston connector 3.96 NB NB NB NB NB
52 964 056 Cable shoe M6 NB NB NB NB NB NB NB
53 964 055 Cable terminal M5 NB NB NB NB NB NB NB
54 265 269 Connector housing 6 pole NB NB
55 265 265 Connector housing 6 pole NB NB
56 265 204 Connector housing 1 pole NB NB
57 265 207 Connector housing 1 pole NB NB
58 847 700 Spacer 6/10/11 1k 1k 1k 1k 1k 1k 1k
59 960 260 Shrink tube coated 1l 1l
60 960 300 Shrink tube coated 48/16 1l 1l
a In a roll, ignition cable 620mm
b in a roll, protection hose, 560mm
c in a roll, ignition cable, 500mm
d in a roll, protection hose 450mm
e No necessary at intake manifold #867 688
f Marked with serial#
g Marked with serial#
h Not suitable for crankcase part# 888 364
i Use only with crankcase# 888 364
j Not suitable to intake manifold #867 688
k Necessary for version with ring mount
l In a roll, use 2cm (.79")
m Use part# 842 742 and 953 390 together only
